Samtec 1 Port Right Angle Through Hole Mount Female Version 2.0 Type B USB Connector

  • RS Stock No. 161-2310
  • Mfr. Part No. USB-B-S-F-B-TH
  • Brand Samtec
Technical Reference
Legislation and Compliance
RoHS Certificate of Compliance
Product Details

USB 2.0 Interface, Type A

Available in black or white insulators
Available in standard or high-retention
Available with though-hole or surface mount tails
Cost saving flash gold plating available
Dual stack jack available

Specifications
Attribute Value
Gender Female
USB Type B
Mounting Type Through Hole
Termination Method Solder
USB Version 2.0
Body Orientation Right Angle
Number of Ports 1
Voltage Rating 30.0 V
Series USB-B
Contact Material Phosphor Bronze
Minimum Operating Temperature -50.0°C
Maximum Operating Temperature +85°C
40 In stock - FREE next working day delivery available
Price Each (In a Tray of 10)
£ 0.657
(exc. VAT)
£ 0.788
(inc. VAT)
Units
Per unit
Per Tray*
10 - 90
£0.657
£6.57
100 - 490
£0.568
£5.68
500 - 990
£0.461
£4.61
1000 - 4990
£0.412
£4.12
5000 +
£0.372
£3.72
*price indicative
