IP67 Black Cap Tactile Switch, Single Pole Single Throw (SPST) 50 mA 1.6mm Through Hole

Technical Reference
Legislation and Compliance
RoHS Certificate of Compliance
COO (Country of Origin): CN
Product Details

TE Connectivity FSM Series Tactile Switches

TE Connectivity brings you a range of professional and brilliant tactile switches. The FSM series of tactile switches are housed in a strong 'Nylon 66' material and feature a moving contact of copper alloy-silver. These tactile switches are great use for mounting on your PCB to close a circuit. The small tactile switches come in THT & SMT mounting styles and excellent quality.

Features and benefits:

• Up to 1 Million operations
• Actuation force of 1.6N to 2.5N
• Small PCB footprint
• Low profile
• 0.25 Actuation travel
• Operating temperatures of -35° up to +85°

Applications:

• Keyboards
• Keypads
• Telephones
• Radios
• General consumer electronics
• Closing the circuit on a PCV

Tactile

Specifications
Attribute Value
Contact Configuration Single Pole Single Throw (SPST)
Terminal Type Solder
Switch Operation Momentary
Actuator Length 1.6mm
Actuator Colour Black
Actuator Type Cap
Length 6.3mm
Width 6.4mm
Dimensions 6.3 x 6.4mm
Illuminated Yes
Mounting Type Through Hole
Contact Current Rating 50 mA
IP Rating IP67
Operating Force 2.6 N
Minimum Operating Temperature -35°C
Operating Temperature Range -35 → +85°C
Maximum Operating Temperature +85°C
Contact Material Brass, Stainless Steel
Mechanical Life 1000000 (Electrical)Cycles
Voltage Rating 24V dc
940 In stock - FREE next working day delivery available
Price Each (In a Pack of 10)
Was £0.65
£ 0.521
(exc. VAT)
£ 0.625
(inc. VAT)
Units
Per unit
Per Pack*
10 +
£0.521
£5.21
*price indicative
