White Rectangular Tactile Switch, SPST 50 mA 2.2mm Surface Mount
- RS Stock No.:
- 124-6915
- Mfr. Part No.:
- FSMIJM63AA04
- Brand:
- TE Connectivity
Available to back order for despatch 11/07/2024
Added
Price Each (In a Pack of 5)
£1.658
(exc. VAT)
£1.99
(inc. VAT)
| Units | Per unit | Per Pack* |
| 5 - 20 | £1.658 | £8.29 |
| 25 - 45 | £1.604 | £8.02 |
| 50 - 95 | £1.55 | £7.75 |
| 100 + | £1.50 | £7.50 |
| *price indicative | ||
- RS Stock No.:
- 124-6915
- Mfr. Part No.:
- FSMIJM63AA04
- Brand:
- TE Connectivity
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- CN
Product Details
TE Alcoswitch Illuminated Tactile Switch Series
The Alcoswitch tactile illuminated switches are easy to operate. They are provided in various board-mounted applications. Illuminated switches are ideal for use with illuminated interfaces via push button style switches.
Features and Benefits
Switches durability rating up to 500,000 electrical life cycles
Design flexibility
LED Indicators high or low intensity
Board space saving
Integrated superbright LED
Quick board assembly
Ease of use with tactile and audible feedback
Design flexibility
LED Indicators high or low intensity
Board space saving
Integrated superbright LED
Quick board assembly
Ease of use with tactile and audible feedback
Applications:
Industrial Equipment
Building / Automation
HVAC equipment
Instrumentation
Communication equipment
Control equipment
Building / Automation
HVAC equipment
Instrumentation
Communication equipment
Control equipment
Tactile
Specifications
Attribute | Value |
|---|---|
| Contact Configuration | SPST |
| Terminal Type | Solder |
| Switch Operation | Momentary |
| Actuator Length | 2.2mm |
| Actuator Colour | White |
| Actuator Type | Rectangular |
| Length | 6.1mm |
| Width | 6.1mm |
| Dimensions | 6.1 x 6.1mm |
| Illuminated | Yes |
| Mounting Type | Surface Mount |
| Contact Current Rating | 50 mA |
| Operating Force | 2.54 N |
| Voltage Rating | 12V dc |
| Height | 7.8mm |
| Minimum Operating Temperature | -25°C |
| Contact Material | Brass |
| Maximum Operating Temperature | +70°C |
| Operating Temperature Range | -25 → +70°C |
