BEL POWER SOLUTIONS INC Switching Regulator, Chassis Mount, Wall Mount, 24.14V dc Output Voltage, 29 → 80V dc
- RS Stock No.:
- 833-7555
- Mfr. Part No.:
- PSC248-7IR
- Brand:
- BEL POWER SOLUTIONS INC
Discontinued product
Alternative
This product is not currently available. Here is our alternative recommendation.
- RS Stock No.:
- 833-7555
- Mfr. Part No.:
- PSC248-7IR
- Brand:
- BEL POWER SOLUTIONS INC
Technical Reference
Legislation and Compliance
RoHS Status: Not Applicable
Product Details
Power One - PSC Series
The PSC series switching regulators are power supplies for electronic systems where no input to output isolation is required. These switching regulators are reliable, have an excellent dynamic response and are highly efficient. Models with input voltages up to 144 V are designed for secondary switched and battery driven mobile applications. The PSC converters are wall or chassis mounted and are suitable for railway applications according to EN 50155 and EN 50121.
Input voltage up to 144 Vdc
Single output of 3.3 to 48 Vdc
High efficiency up to 97%
Extremely wide input voltage range
Low input to output differential voltage
Very good dynamic properties
Input under voltage lockout
Output voltage adjustment and inhibit function
Continuously no-load and short circuit proof
Single output of 3.3 to 48 Vdc
High efficiency up to 97%
Extremely wide input voltage range
Low input to output differential voltage
Very good dynamic properties
Input under voltage lockout
Output voltage adjustment and inhibit function
Continuously no-load and short circuit proof
Approvals
IEC, EN, UL,CSA
Specifications
Attribute | Value |
---|---|
Output Voltage | 24.14V dc |
Output Current | 8A |
Input Voltage | 29 → 80V dc |
Mounting Type | Chassis Mount, Wall Mount |
Number of Outputs | 1 |
Package | C03 |
Power Rating | 192W |
Efficiency | 95% |
Ripple And Noise | 155mV Pk-Pk |
Minimum Temperature | -25°C |
Maximum Temperature | +71°C |
Line Regulation | 220mV |
Depth | 32.2mm |
Width | 88mm |
Weight | 440g |
Load Regulation | 160mV |
MTBF | 2800000h |
Length | 151mm |
