BEL POWER SOLUTIONS INC Screw Mount Switching Regulator, 24V dc Output Voltage, 29 60V dc Input Voltage, 2.5A

Technical Reference
Legislation and Compliance
Non Compliant
COO (Country of Origin): SK
Product Details

Positive Switching Regulators

Wide input voltage range
High current output
High efficiency
Low input to output differential voltage
Very good dynamic properties
Input undervoltage lock-out
Parallel configurations possible
Continuous no-load and short-circuit proof
No derating

Standards

UL 1950, UL 1012, EN60950

//media.rs-online.com/t_line/L466751-01.gif
//media.rs-online.com/t_line/LF466751-01.gif
Specifications
Attribute Value
Input Voltage 29 60V dc
Output Voltage 24V dc
Number of Outputs 1
Output Current 2.5A
Power Rating 60W
Mounting Type Screw Mount
Minimum Temperature -10°C
Maximum Temperature +50°C
Length 50.2mm
Depth 25.2mm
Width 70.2mm
1 In stock for FREE next working day delivery
Price Each
Was £127.03
£ 75.13
(exc. VAT)
£ 90.16
(inc. VAT)
Units
Per unit
1 +
£75.13
