onsemi Switching Diode, 1A 600V, 2-Pin DO-214AC S1J
- RS Stock No.:
- 903-4406
- Mfr. Part No.:
- S1J
- Brand:
- onsemi
1600 In stock - FREE next working day delivery available
400 available from Europe for delivery within 1 working day(s).
Added
Price Each (In a Pack of 100)
£0.097
(exc. VAT)
£0.116
(inc. VAT)
| Units | Per unit | Per Pack* |
| 100 - 400 | £0.097 | £9.70 |
| 500 - 900 | £0.092 | £9.20 |
| 1000 - 2400 | £0.069 | £6.90 |
| 2500 - 7400 | £0.056 | £5.60 |
| 7500 + | £0.054 | £5.40 |
| *price indicative | ||
- RS Stock No.:
- 903-4406
- Mfr. Part No.:
- S1J
- Brand:
- onsemi
Technical Reference
Legislation and Compliance
Product Details
Rectifier Diodes, 1A to 1.5A, Fairchild Semiconductor
Diodes and Rectifiers, ON Semiconductor
Whether you are working on a new design, or purchasing, ON Semiconductor provides you with industry-standard diodes and rectifiers, small signal diodes, Schottky and Zener diodes. The components offer the best available combination of quality, features, and packaging options.
Specifications
Attribute | Value |
|---|---|
| Maximum Forward Current | 1A |
| Diode Configuration | Single |
| Number of Elements per Chip | 1 |
| Mounting Type | Surface Mount |
| Maximum Reverse Voltage | 600V |
| Package Type | DO-214AC (SMA) |
| Diode Technology | Silicon Junction |
| Pin Count | 2 |
| Maximum Forward Voltage Drop | 1.1V |
| Minimum Operating Temperature | -55 °C |
| Maximum Operating Temperature | +150 °C |
| Length | 4.75mm |
| Width | 2.95mm |
| Height | 2.2mm |
| Dimensions | 4.75 x 2.95 x 2.2mm |
| Power Dissipation | 1.4W |
