- RS Stock No.:
- 535-2637
- Mfr. Part No.:
- PSD2425
- Brand:
- Sensata / Crydom
19 In stock - FREE next working day delivery available
Added
Price Each
£87.69
(exc. VAT)
£105.23
(inc. VAT)
Units | Per unit |
1 - 4 | £87.69 |
5 - 9 | £83.31 |
10 - 24 | £78.92 |
25 - 49 | £74.54 |
50 + | £70.15 |
- RS Stock No.:
- 535-2637
- Mfr. Part No.:
- PSD2425
- Brand:
- Sensata / Crydom
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- MX
Product Details
Series PS Peak Switching Relay
AC switching to 280Vac
AC load switching to 50A
Peak voltage switching
Panel mount
Dimensions: H22.9 x W45.7 x D47.5
AC load switching to 50A
Peak voltage switching
Panel mount
Dimensions: H22.9 x W45.7 x D47.5
Note
Heat sink not included. For load current de-rating and heat sink details see manufacturers datasheet
Caution
Derating will limit the maximum load current at temperatures above 25 °C
Approvals
UL/cUL
Approvals
UL/cUL
Peak Switching
Specifications
Attribute | Value |
---|---|
Maximum Load Current | 25 A rms |
Mounting Type | Panel Mount |
Maximum Load Voltage | 280 V rms |
Maximum Control Voltage | 32 V |
Switching Type | DC |
Control Voltage Range | 3 → 32 V dc |
Minimum Load Current | 40 mA |
Output Device | SCR |
Load Voltage Range | 90 → 280V ac |
Dimensions | 45.7 x 58.4 x 23mm |
Depth | 58.4mm |
Height | 23mm |
Length | 45.7mm |
Operating Temperature Range | -40 → +80°C |
Maximum Operating Temperature | +80°C |
Minimum Operating Temperature | -40°C |
