Phoenix Contact 30 A SPNO Solid State Relay, DC/AC, PCB Mount, 66 V dc Maximum Load

Technical Reference
Legislation and Compliance
RoHS Certificate of Compliance
COO (Country of Origin): DE
Product Details

The Phoenix Contact plug-in miniature solid-state relay has switching power of up to 24Vdc/5A and can be soldered on PCB.

Zero voltage switch at AC output
Vibration and shock resistant
RT III-proof
Wear-free and durable

Specifications
Attribute Value
Minimum Load Current 10 mA
Maximum Load Current 30 A
Range Single Solid-State Relays
Series OPT
Mounting Type PCB Mount
Minimum Load Voltage 54 V dc
Maximum Load Voltage 66 V dc
Switching Type DC/AC
Contact Configuration SPNO
Available to back order for despatch 07/10/2020, delivery within 2 working days
Price Each (In a Pack of 10)
£ 21.301
(exc. VAT)
£ 25.561
(inc. VAT)
Units
Per unit
Per Pack*
10 +
£21.301
£213.01
*price indicative
Not available for guaranteed pre 9am/10am delivery
