i-Autoc KSI Series Solid State Relay, 60 A Load, Panel Mount, 280 V ac Load, 32 V dc Control

RS Stock No.:: 164-0578
Mfr. Part No.:: KSI240D60R-L
Brand:: i-Autoc

i-Autoc KSI Series Solid State Relay, 60 A Load, Panel Mount, 280 V ac Load, 32 V dc Control

11 In stock - FREE next working day delivery available

Added

Price Each

£26.80

(exc. VAT)

£32.16

(inc. VAT)

Units	Per unit
1 +	£26.80

RS Stock No.:: 164-0578
Mfr. Part No.:: KSI240D60R-L
Brand:: i-Autoc

Technical Reference

Datasheet

Legislation and Compliance

COO (Country of Origin):: CN

Product Details

KSI series single phase solid state relay use the Triac or SCR output. It is widely used in various industry applications, and it can be used for the resistive, inductive or capacitive loads. The control voltage is 4-32VDC or 90-280VAC, load voltage is 240VAC, 380VAC, 480VAC or 600VAC. Wide load current range from 10 to 125A.

Zero crossing or Random-on
Load current:10A-125A @48-660VAC
TRIAC or SCR output
AC or DC control
Dielectric strength ≥4000VACrms
LED indicator
Build-in MOV or TVS option

Specifications

Attribute	Value
Maximum Load Current	60 A
Mounting Type	Panel Mount
Maximum Load Voltage	280 V ac
Minimum Load Voltage	48 V ac
Maximum Control Voltage	32 V dc
Minimum Control Voltage	4 V dc
Switching Type	Random
Control Voltage Range	4 → 32 V dc
Terminal Type	Screw
Output Device	SCR, TRIAC
Relay Type	Single Phase
Load Voltage Range	48 → 280V ac
Maximum Turn On Time	1ms
Series	KSI
Dimensions	58.4 x 45.7 x 20.5mm
Depth	45.7mm
Operating Temperature Range	-30 → +80°C
Height	20.5mm
Standards Met	CCCs, CE, CULus, TUV
Minimum Operating Temperature	-30°C
Off State Leakage Current	5 mA
Length	58.4mm
Special Features	Build-In MOV/TVS Option, DC Control, Dielectric Strength, LED Indicator, TRIAC or SCR Output
Maximum Operating Temperature	+80°C
