i-Autoc Solid State Relay, 4 A Load, PCB Mount, 58 V dc Load, 15 V dc Control
- RS Stock No.:
- 102-5532
- Mfr. Part No.:
- KSMD48D4-12
- Brand:
- i-Autoc
3 In stock - FREE next working day delivery available
Added
Price Each
£18.93
(exc. VAT)
£22.72
(inc. VAT)
| Units | Per unit |
| 1 + | £18.93 |
- RS Stock No.:
- 102-5532
- Mfr. Part No.:
- KSMD48D4-12
- Brand:
- i-Autoc
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- CN
Product Details
KSMD Series Single Phase SSR
I-Autoc KSMD series single phase AC output PCB mount solid state relay. KSMD relays have various control voltage options available with a load current at 0.1A, 2A, 3A or 4A. Suitable for high density PCB mounted or PLC control applications.
PCB Mounted
Opto-isolation
Dielectric strength 2500 Vrms
RoHS compliant
Opto-isolation
Dielectric strength 2500 Vrms
RoHS compliant
I-Autoc PCB Mounting SSR
Specifications
Attribute | Value |
|---|---|
| Maximum Load Current | 4 A |
| Mounting Type | PCB Mount |
| Maximum Load Voltage | 58 V dc |
| Minimum Load Voltage | 0 V dc |
| Maximum Control Voltage | 15 V dc |
| Minimum Control Voltage | 10 V dc |
| Switching Type | DC |
| Control Voltage Range | 10 → 15 V dc |
| Minimum Load Current | 0.001 A |
| Terminal Type | PCB Pin |
| Relay Type | Single Phase |
| Load Voltage Range | 0 → 58V dc |
| Maximum Turn On Time | 0.05ms |
| Dimensions | 28.2 x 5.2 x 15mm |
| Depth | 5.2mm |
| Off State Leakage Current | 100 μA |
| Standards Met | CE, cULus |
| Special Features | COMS Drive Compatible, Optoelectronic Isolation, TTL |
| Operating Temperature Range | -30 → +80°C |
| Length | 28.2mm |
| Height | 15mm |
