- RS Stock No.:
- 146-9280
- Brand:
- RS PRO
- RS Stock No.:
- 146-9280
- Brand:
- RS PRO
Legislation and Compliance
RoHS Status: Not Applicable
- COO (Country of Origin):
- CN
Product Details
The series designations in accordance with
ISO 355 consist of a digit and two letters.
The digit represents the contact angle. The two letters represent the diameter and width series, respectively.
This is followed by a three-digit bore diameter d [mm].
The basic designations of SKF tapered roller bearings start with the letter T, e.g.T2ED 045.
ISO 355 consist of a digit and two letters.
The digit represents the contact angle. The two letters represent the diameter and width series, respectively.
This is followed by a three-digit bore diameter d [mm].
The basic designations of SKF tapered roller bearings start with the letter T, e.g.T2ED 045.
Specifications
Attribute | Value |
---|---|
Inside Diameter | 35mm |
Outside Diameter | 62mm |
Roller Bearing Type | Taper |
Race Width | 18mm |
Bore Type | Tapered |
Static Load Rating | 54kN |
Cage Material | Steel |
Number of Rows | 1 |
Dynamic Load Rating | 52.3kN |
End Type | Open |
Limiting Speed | 10000rpm |
Reference Speed | 8500rpm |
Fatigue Limit Load | 5.85kN |
