- RS Stock No.:
- 790-6996
- Mfr. Part No.:
- 19323-0016
- Brand:
- Molex
1200 In stock - FREE next working day delivery available
350 available from Europe for delivery within 1 working day(s).
Added
Price Each (In a Pack of 50)
£0.536
(exc. VAT)
£0.643
(inc. VAT)
Units | Per unit | Per Pack* |
50 - 200 | £0.536 | £26.80 |
250 + | £0.515 | £25.75 |
*price indicative |
- RS Stock No.:
- 790-6996
- Mfr. Part No.:
- 19323-0016
- Brand:
- Molex
Legislation and Compliance
- COO (Country of Origin):
- US
Product Details
Molex VersaKrimp Uninsulated Crimp Ring Terminals
Avikrimp™ insulated metric crimp ring terminals with a seamless barrel and halogen free nylon insulation. These Avikrimp™ insulated crimp ring terminals are made from oxygen free copper with tin plating and have a tin plated brass ferrule. A double crimp is created with both the conductor and insulation which provides good vibration resistance. The seamless barrel of these Avikrimp™ crimp ring terminals enables easier crimping by allowing the barrel to rotate in the crimping jaws.
Molex VersaKrimp Series Ring Terminal, Copper Alloy Contact Material, Uninsulated Insulation - 19323-0016
This copper alloy ring terminal by Molex is a top-quality product designed for efficient electrical connections. With tin plating this terminal ensures reliable performance and durability.
Features & Benefits
• Copper alloy construction ensures high conductivity and resistance to corrosion
• Tin plating provides excellent protection against oxidation, extending the product's lifespan
• Insulated design prevents electrical shorts and enhances safety during usage.
• Tin plating provides excellent protection against oxidation, extending the product's lifespan
• Insulated design prevents electrical shorts and enhances safety during usage.
Applications
• Ideal for use in automotive wiring projects
• Suitable for industrial machinery wiring connections
• Can be used for electrical panel installations
• Suitable for industrial machinery wiring connections
• Can be used for electrical panel installations
Can it handle different wire sises efficiently?
Yes, it is designed to accommodate wire sises ranging from 2.5mm² to 6mm².
Will it provide reliable conductivity?
Yes, the copper alloy material ensures high conductivity for effective electrical connections.
Is it suitable for outdoor applications?
Yes, the tin plating protects the terminal from corrosion, making it suitable for outdoor use.
Can it be used with M10 studs?
Yes, the terminal is compatible with M10 stud sises for secure connections.
Does it come in different dimensions?
Yes, the terminal is available in varying sises to suit different project requirements.
Specifications
Attribute | Value |
---|---|
Series | VersaKrimp |
Insulation | Uninsulated |
Outer Ring Diameter | 14.94mm |
Inner Ring Diameter | 10.63mm |
Minimum Wire Size mm² | 2.5mm² |
Maximum Wire Size mm² | 6mm² |
Stud Size | M10 |
Contact Plating | Tin |
Contact Material | Copper Alloy |
Thickness | 1.02mm |
Overall Length | 21.5mm |
