Roxburgh EMC, MDF 16A 250 V ac 60Hz, Panel Mount RFI Filter, Single Phase
- RS Stock No.:
- 264-8799
- Mfr. Part No.:
- MDF16
- Brand:
- Roxburgh EMC
16 In stock - FREE next working day delivery available
Added
Price Each
£133.24
(exc. VAT)
£159.89
(inc. VAT)
| Units | Per unit |
| 1 - 4 | £133.24 |
| 5 - 9 | £123.91 |
| 10 - 24 | £115.93 |
| 25 + | £109.26 |
- RS Stock No.:
- 264-8799
- Mfr. Part No.:
- MDF16
- Brand:
- Roxburgh EMC
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- GB
Product Details
MDF Series
Motor drive two stage high performance filters, suitable for a wide range of industrial motor drive applications
Compact and flexible filters
Designed to comply with IEC950 safety standards
Connection via screw terminals
Compact and flexible filters
Designed to comply with IEC950 safety standards
Connection via screw terminals
Approvals
UL; CSA; VDE
Specifications
Attribute | Value |
|---|---|
| Maximum Current Rating | 16A |
| Maximum Voltage Rating | 250 V ac |
| Mounting Type | Panel Mount |
| Number of Phases | 1 |
| Series | MDF |
| Operating Frequency | 60Hz |
| Length | 150mm |
| Depth | 65mm |
| Height | 48mm |
| Capacitance | 1µF |
| Dimensions | 150 x 65 x 48mm |
| Inductance | 1 mH |
| Leakage Current | 4.98 mA |
| Minimum Operating Temperature | -25°C |
| Maximum Operating Temperature | +85°C |
| Resistance | 9.8mΩ |
| Standards Met | UL 1283 |
| Power Loss | 2.5W |
