Vishay 20kΩ Rotary Potentiometer 10-Turns 1-Gang Bushing Mount, 534-1-1-203
- RS Stock No.:
- 850-9805
- Mfr. Part No.:
- 534-1-1-203
- Brand:
- Vishay
83 In stock - FREE next working day delivery available
Added
Price Each
£18.50
(exc. VAT)
£22.20
(inc. VAT)
| Units | Per unit |
| 1 - 4 | £18.50 |
| 5 - 9 | £13.88 |
| 10 - 24 | £11.66 |
| 25 - 49 | £11.10 |
| 50 + | £10.18 |
- RS Stock No.:
- 850-9805
- Mfr. Part No.:
- 534-1-1-203
- Brand:
- Vishay
Legislation and Compliance
Product Details
Vishay 534 Series Wirewound Potentiometers - 10 Turns
• 10 Turns
• Bushing and servo mount designs available
• Linearity ± 0.25 %, down to 0.05 % on request
• Special resistance tolerances to 1 %
• Rear shaft extensions and support bearing
• Metric shaft available
• Dual gang configuration and concentric shafts
• High torque, center tap, slipping clutch on request
• Special markings and front shaft extensions
• Bushing and servo mount designs available
• Linearity ± 0.25 %, down to 0.05 % on request
• Special resistance tolerances to 1 %
• Rear shaft extensions and support bearing
• Metric shaft available
• Dual gang configuration and concentric shafts
• High torque, center tap, slipping clutch on request
• Special markings and front shaft extensions
Note
* Mounting kit is not required when used with servo pot mounting kit. It is essential to prevent rotation of the shaft beyond the mechanical travel of 360°x10 turns.
Precision - Multi-Turn and Servo
Specifications
Attribute | Value |
|---|---|
| Potentiometer Type | Rotary |
| Maximum Resistance | 20kΩ |
| Number of Gangs | 1 |
| Number of Turns | 10 |
| Power Rating | 2W |
| Electrical Taper | Linear |
| Element Material | Wirewound |
| Mounting Type | Bushing Mount |
| Termination Style | Turret |
| Shaft Length | 20.6mm |
| Shaft Diameter | 6.35 mm |
| Tolerance | ±5% |
| Actuator Type | Slotted Shaft |
| Series | 534 |
