Vishay 50kΩ Rotary Potentiometer 5-Turns 1-Gang Panel Mount, 535B1503JC
- RS Stock No.:
- 460-1950
- Mfr. Part No.:
- 535B1503JC
- Brand:
- Vishay
5 In stock - FREE next working day delivery available
Added
Price Each
£32.31
(exc. VAT)
£38.77
(inc. VAT)
| Units | Per unit |
| 1 - 1 | £32.31 |
| 2 - 4 | £30.69 |
| 5 - 9 | £21.00 |
| 10 - 24 | £19.36 |
| 25 + | £18.86 |
- RS Stock No.:
- 460-1950
- Mfr. Part No.:
- 535B1503JC
- Brand:
- Vishay
Legislation and Compliance
- COO (Country of Origin):
- SK
Product Details
Vishay 535 Series Wirewound Potentiometers - 5 Turns
• Bushing and servo mount designs available
• Linearity ± 0.25 %, down to 0.05 % on request
• Special resistance tolerances to 1 %
• Rear shaft extensions and support bearing
• Metric shaft available
• Dual gang configuration and concentric shafts
• High torque, center tap, slipping clutch on request
• Special markings and front shaft extensions
• Linearity ± 0.25 %, down to 0.05 % on request
• Special resistance tolerances to 1 %
• Rear shaft extensions and support bearing
• Metric shaft available
• Dual gang configuration and concentric shafts
• High torque, center tap, slipping clutch on request
• Special markings and front shaft extensions
Supplied with
Metal lockwasher and nut.
Precision - Multi-Turn and Servo
Specifications
Attribute | Value |
|---|---|
| Potentiometer Type | Rotary |
| Maximum Resistance | 50kΩ |
| Number of Gangs | 1 |
| Number of Turns | 5 |
| Power Rating | 1.5W |
| Electrical Taper | Linear |
| Element Material | Wirewound |
| Mounting Type | Panel Mount |
| Termination Style | Solder Lug |
| Shaft Length | 22.2mm |
| Shaft Diameter | 6.35 mm |
| Actuator Type | Slotted Shaft |
| Tolerance | ±5% |
| Series | 535 |
