- RS Stock No.:
- 177-0519
- Mfr. Part No.:
- 16194
- Brand:
- Volkel
3 In stock - FREE next working day delivery available
2 available from Europe for delivery within 1 working day(s).
Price Each
£51.93
(exc. VAT)
£62.32
(inc. VAT)
Units | Per unit |
1 + | £51.93 |
Calibration Options:
- RS Stock No.:
- 177-0519
- Mfr. Part No.:
- 16194
- Brand:
- Volkel
Technical Reference
Legislation and Compliance
RoHS Status: Not Applicable
- COO (Country of Origin):
- DE
Product Details
Volkel Go Ring Gauge
The Volkel No-Go ring gauge M8x1.25 is calibrated at a measurement laboratory using IAC thread scanners. This No-Go thread gauge is marked in red. It must not screw into the part by hand by more than two threads. The reference temperature for parts and gauge is 20°C. It is made from high-quality raw material. This gauge is mostly used as an inspection tool.
Features and Benefits
Metric measurement system
6g tolerance
High durability and reliability
Compact size and rugged
Easy to use
Accurate
6g tolerance
High durability and reliability
Compact size and rugged
Easy to use
Accurate
Certifications
ISO1502
DIN13
DIN13
Certifications
ISO1502
DIN13
DIN13
Specifications
Attribute | Value |
---|---|
Plug/Ring | Ring |
Gauge Type | Ring Thread Gauge |
Go / No Go | Go |
Thread Size | M8 x 1.25 |
Pitch Diameter | 1.25mm |
Tolerance | 6g |
Imperial or Metric | Metric |
