Hirose A4B Series Straight Through Hole Pin Header, 6 Contact(s), 2.0mm Pitch, 1 Row(s), Unshrouded
- RS Stock No.:
- 172-1781
- Mfr. Part No.:
- A4B-6PA-2DSA(51)
- Brand:
- Hirose
70 In stock - FREE next working day delivery available
Added
Price Each (In a Pack of 10)
£0.352
(exc. VAT)
£0.422
(inc. VAT)
| Units | Per unit | Per Pack* |
| 10 - 40 | £0.352 | £3.52 |
| 50 - 90 | £0.334 | £3.34 |
| 100 - 240 | £0.296 | £2.96 |
| 250 + | £0.28 | £2.80 |
| *price indicative | ||
- RS Stock No.:
- 172-1781
- Mfr. Part No.:
- A4B-6PA-2DSA(51)
- Brand:
- Hirose
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- JP
Product Details
Miniature Type and High Density Mounting: These connectors are designed in a miniature and light weight product, and mounted in the high density. The crimping case is structured in the 2mm pitch grid, so that connectors can be arranged for use.
Variation in Number of Contacts: In addition to the dip type, SMT and crimping types are available with broad variations.
Stacking Variation: When the connector is used for board to board, set 6mm between boards in conjunction with the pin header A3B, or 5.1mm between boards in conjunction with the pin header A3C
Variation in Number of Contacts: In addition to the dip type, SMT and crimping types are available with broad variations.
Stacking Variation: When the connector is used for board to board, set 6mm between boards in conjunction with the pin header A3B, or 5.1mm between boards in conjunction with the pin header A3C
Specifications
Attribute | Value |
|---|---|
| Series | A4B |
| Pitch | 2.0mm |
| Number of Contacts | 6 |
| Number of Rows | 1 |
| Body Orientation | Straight |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Wire to Board |
| Mounting Type | Through Hole |
| Termination Method | Solder |
| Contact Plating | Gold |
| Contact Material | Brass |
| Current Rating | 1.0A |
| Tail Pin Length | 2.6mm |
| Mating Pin Length | 3.5mm |
| Voltage Rating | 200.0 V |
