Samtec HTST Series Straight Surface Mount PCB Header, 10 Contact(s), 2.54mm Pitch, 2 Row(s), Shrouded
- RS Stock No.:
- 159-2342
- Mfr. Part No.:
- HTST-105-01-S-DV
- Brand:
- Samtec
- RS Stock No.:
- 159-2342
- Mfr. Part No.:
- HTST-105-01-S-DV
- Brand:
- Samtec
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- MY
Product Details
.100" High-Temp Shrouded Terminal Strip, Cable Mate
Most common pin counts from 10 to 72
Polarization notch
.100" (2.54 mm) pitch
Through-hole, right-angle and surface mount
Polarization notch
.100" (2.54 mm) pitch
Through-hole, right-angle and surface mount
Specifications
Attribute | Value |
---|---|
Series | HTST |
Pitch | 2.54mm |
Number of Contacts | 10 |
Number of Rows | 2 |
Body Orientation | Straight |
Shrouded/Unshrouded | Shrouded |
Mounting Type | Surface Mount |
Connector System | Wire to Board |
Termination Method | Solder |
Contact Material | Phosphor Bronze |
Contact Plating | Gold |
Current Rating | 3.4A |
Voltage Rating | 1.0 kV |
