RS PRO 850W PC Power Supply, 200 → 240V ac Input, ±12 V dc, 3.3 V dc, 5 V dc Output

Technical Reference
Legislation and Compliance
RoHS Certificate of Compliance
COO (Country of Origin): CN
Product Details

RS Pro Modular ATX Power Supply, 850 W

Robust & efficient modular 850 W power supply ensuring a reliable power solution for various applications such as office installations, gaming & servers. Comes equipped with a silent-running 120 mm fan, low ripple noise & mesh-cabled connectors.

Features and Benefits

•80 Plus Bronze energy efficiency rating.
•Compliant with the latest Intel ATX12V Ver.2.4 design guide.
•DC cabling comes equipped with a mesh sleeve to aid with airflow interference reduction.
•Compatible with Intel's HASWELL CPU C6/C7 power-saving mode.
•Designed for use with high-end GPU's thanks to the PCIE 6+2 pin termination.
•Able to support up to 7 SATA compatible drives.
•120 mm silent-running fan with integrated smart thermal fan speed control circuit.

Standards

CE, CB, & TUV Certified. OVP, UVP, OPP, SCP & SIP Protection. RoHS & ErP 2013 rated.

Specifications
Attribute Value
Input Voltage 200 → 240V ac
Output Voltage ±12 V dc, 3.3 V dc, 5 V dc
Power Rating 850W
Output Current 0.3 → 65A
Number of Outputs 1
Mounting Type DIN Rail
Efficiency >82%
Standards Met 80 Plus Bronze Certified
Power Signal Conversion Type AC-DC
9 In stock - FREE next working day delivery available
Price Each
£ 78.00
(exc. VAT)
£ 93.60
(inc. VAT)
Units
Per unit
1 - 4
£78.00
5 - 9
£75.66
10 - 24
£73.32
25 - 49
£70.98
50 +
£68.64
