Silicon Labs Surface Mount Hall Effect Sensor Switch, SOT-23, 5-Pin
- RS Stock No.:
- 144-1563
- Mfr. Part No.:
- Si7205-B-00-IVR
- Brand:
- Silicon Labs
Available to back order for despatch when stock is available
Added
Price Each (On a Reel of 3000)
£0.549
(exc. VAT)
£0.659
(inc. VAT)
| Units | Per unit | Per Reel* |
| 3000 - 6000 | £0.549 | £1,647.00 |
| 9000 - 12000 | £0.505 | £1,515.00 |
| 15000 - 27000 | £0.464 | £1,392.00 |
| 30000 - 57000 | £0.428 | £1,284.00 |
| 60000 + | £0.393 | £1,179.00 |
| *price indicative | ||
- RS Stock No.:
- 144-1563
- Mfr. Part No.:
- Si7205-B-00-IVR
- Brand:
- Silicon Labs
Technical Reference
Legislation and Compliance
Product Details
Si720x Series Hall Effect Magnetic Sensors
A range of Hall-effect magnetic sensors from Silicon Labs. The devices combine chopper-stabilized Hall elements, low-noise amplifiers, 13-bit ADCs and comparators to produce high precision magnetically activated switches. The device output changes state if the pre-programmed magnetic threshold is crossed, and the range includes versions with a tamper indication facility. Typical applications include security system magnetic detection, position sensing and revolution counting.
• Industry-leading sensitivity allows use with larger air gaps and smaller magnets
• Low power consumption to improve operating life in battery powered applications
• Low voltage (1.7-5.5V) and High voltage (3.3-26.5V) versions
• Unipolar switching and Latch versions available
• Compact 3-pin SOT23 package
• AEC-Q100 Qualified for automotive applications
• Low power consumption to improve operating life in battery powered applications
• Low voltage (1.7-5.5V) and High voltage (3.3-26.5V) versions
• Unipolar switching and Latch versions available
• Compact 3-pin SOT23 package
• AEC-Q100 Qualified for automotive applications
Hall Effect Sensors, Silicon Labs
Specifications
Attribute | Value |
|---|---|
| Sensor Type | Hall Effect Sensors |
| Mounting Type | Surface Mount |
| Magnetic Type | Omnipolar |
| Maximum Operating Supply Voltage | 26.5 V |
| Minimum Operating Supply Voltage | 3.3 V |
| Package Type | SOT-23 |
| Pin Count | 5 |
| Maximum Operating Temperature | +125 °C |
| Minimum Operating Temperature | -40 °C |
| Automotive Standard | AEC-Q100 |
