- RS Stock No.:
- 179-5980
- Mfr. Part No.:
- C4532C0G2J473J320KA
- Brand:
- TDK
Discontinued product
- RS Stock No.:
- 179-5980
- Mfr. Part No.:
- C4532C0G2J473J320KA
- Brand:
- TDK
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- JP
Product Details
Advanced design provides improved withstand voltage characteristics.
TDK's proprietary intemal electrode structure and the use of low dielectric-strength material result in highly reliable performance in high voltage applications.
Designed exclusively for reflow soldering
Applications
Inverter circuits with a liquid crystal backlight
LAN card
General high voltage circuits
Noise bypass for power supply
Transceiver for LAN
Hub, etc.
TDK's proprietary intemal electrode structure and the use of low dielectric-strength material result in highly reliable performance in high voltage applications.
Designed exclusively for reflow soldering
Applications
Inverter circuits with a liquid crystal backlight
LAN card
General high voltage circuits
Noise bypass for power supply
Transceiver for LAN
Hub, etc.
Specifications
Attribute | Value |
---|---|
Capacitance | 47nF |
Voltage | 630V dc |
Package/Case | 1812 (4532M) |
Mounting Type | Surface Mount |
Dielectric | C0G |
Tolerance | ±5% |
Dimensions | 4.5 x 3.2 x 3.2mm |
Length | 4.5mm |
Depth | 3.2mm |
Height | 3.2mm |
Series | C |
Suppression Class | Class 1 |
Maximum Operating Temperature | +125°C |
Minimum Operating Temperature | -55°C |
