KEMET 100nF Multilayer Ceramic Capacitor MLCC 50V dc ±10% Through Hole C320C104K5R5TA

  • RS Stock No. 146-6304
  • Mfr. Part No. C320C104K5R5TA
  • Brand KEMET
Technical Reference
Legislation and Compliance
RoHS Certificate of Compliance
COO (Country of Origin): MX
Product Details

C315/C317/C320/C322/C330/C331 Series

Professional range of high-voltage multilayer ceramic capacitors. At high frequencies, these capacitors exhibit low ESR and find conventional use as snubbers or filters in applications. These capacitors are typically used in telecommunications, medical, military and aerospace equipment.

X7R dielectric
Conformally coated
Radial

KEMET Multilayer Ceramic Capacitors (MLCCs) are a preferred capacitance solution, offering tremendous performance, reliability and cost advantages for circuit designers.

KEMET’s Goldmax conformally coated radial leaded ceramic capacitors in C0G dielectric feature a 125°C maximum operating temperature. These devices meets the flame test requirements outlined in UL Standard 94V–0.

200 MHz/330 DMIPS, MIPS32 microAptiv core
Dual Panel Flash for live update support
12-bit, 18 MSPS, 45-channel ADC module
Memory Management Unit for optimum embedded OS execution
microMIPS mode for up to 35% code compression
CAN, UART, I2C, PMP, EBI, SQI & Analog Comparators
SPI/I2S interfaces for audio processing and playback
Hi-Speed USB Device/Host/OTG
10/100 Mbps Ethernet MAC with MII and RMII interface
Advanced Memory Protection
2MB Flash memory (plus an additional 160 KB of Boot Flash)
640KB SRAM memory

X7R Dielectric

Suitable for bypass, decoupling, filtering, sample and hold and timing circuits

Specifications
Attribute Value
Capacitance 100 nF
Voltage 50 V dc
Mounting Type Through Hole
Dielectric X7R
Tolerance ±10%
Dimensions 5.08 x 3.81 x 6.6mm
Length 5.08mm
Depth 3.81mm
Height 6.6mm
Series Goldmax 300
Minimum Operating Temperature -55°C
Maximum Operating Temperature +125°C
Lead Spacing 2.54 mm
90000 In stock - FREE next working day delivery available
Price Each (On a Reel of 500)
£ 0.111
(exc. VAT)
£ 0.133
(inc. VAT)
Units
Per unit
Per Reel*
500 - 500
£0.111
£55.50
1000 - 1000
£0.094
£47.00
1500 +
£0.083
£41.50
*price indicative
