eldoLED LED Driver, 55V Output, 30W Output, 150 → 1400mA Output, Constant Current Dimmable
- RS Stock No.:
- 143-8888
- Mfr. Part No.:
- EC0360A6
- Brand:
- eldoLED
Available to back order for despatch 25/06/2024
Added
Price Each (In a Box of 50)
£34.314
(exc. VAT)
£41.177
(inc. VAT)
| Units | Per unit | Per Box* |
| 50 - 50 | £34.314 | £1,715.70 |
| 100 + | £32.393 | £1,619.65 |
| *price indicative | ||
- RS Stock No.:
- 143-8888
- Mfr. Part No.:
- EC0360A6
- Brand:
- eldoLED
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- MX
Product Details
Natural dimming to 1% (Hybrid HydraDrive)
Symbiosis: add value with sensing, connecting, protecting, tooling, communicating, sharing and lighting dynamics features
Programmable to fit application
Independent driver
Low inrush and THD
High power factor and efficiency
Compatible with HD studio camera
EN 61347-1/-2-13, EN 62384, EN 55015, EN 55022, EN 61000-3-2, EN 61547, EN 62386-101/102/207
UL: Recognized Component (E333135), according to UL1310 and UL8750. US/Canada: Class 2 output
ENEC by DEKRA
EL
RCM by SAA
Symbiosis: add value with sensing, connecting, protecting, tooling, communicating, sharing and lighting dynamics features
Programmable to fit application
Independent driver
Low inrush and THD
High power factor and efficiency
Compatible with HD studio camera
EN 61347-1/-2-13, EN 62384, EN 55015, EN 55022, EN 61000-3-2, EN 61547, EN 62386-101/102/207
UL: Recognized Component (E333135), according to UL1310 and UL8750. US/Canada: Class 2 output
ENEC by DEKRA
EL
RCM by SAA
ECOdrive, a programmable digital LED driver, provides standard LED fixtures with the smoothest flicker-free dimming to 1%. It has a single configurable constant current LED output, making it simple to design in. Symbiosis ensures the LED driver works seamlessly together with LED modules, controls and intelligent luminaire elements.
Specifications
Attribute | Value |
|---|---|
| Output Voltage | 55V |
| Maximum Output Power | 30W |
| Output Current | 150 → 1400mA |
| Dimmable | Yes |
| Input Voltage | 120 → 250 V dc, 120 → 250 (ENEC) V ac, 120 → 277 (UL) V ac |
| Operation | Constant Current |
| LED Driver Type | LED Driver |
| Dimming Operation | DALI |
| Output | 55 V @ 150 → 1400 mA |
| Current Rating | 350mA |
| Number of Outputs | 1 |
| Series | Ecodrive |
| Voltage Rating | 120 → 250 V ac, 120 → 250 V dc, 120 → 277 V ac |
| Configuration | Enclosed |
| Primary Type | AC-DC |
