Mean Well ELG-100-C350B, Constant Current LED Driver 100W 286V 350mA, ELG-100-C Series

  • RS Stock No. 103-4352
  • Mfr. Part No. ELG-100-C350B
  • Brand Mean Well
Technical Reference
Legislation and Compliance
RoHS Certificate of Compliance
COO (Country of Origin): CN
Product Details

Mean Well ELG-100C Series Dimmable LED Driver

Mean Well ELG-100C series of constant current 100 W dimmable LED Driver, which also supports a high-voltage constant output. Thanks to a fan-less design, the ELG-100C series provides an efficiency rating of up to 91%. Constructed in a robust full metal housing to ensure suitability with a wide variety of applications.

•Fan-less design provides high efficiency rating.
•Wide operating temperature range.
•Rated to IP 65/67 depending on the option selected.
•Designed to provide the optimal flexibility for LED applications.
•Both Potentiometer and PWM signal dimming options available.
•Class 2 power unit.
•Built-in active PFC function.

Typical applications include LED street lighting, architectural lighting, bay lighting & floodlighting.

Mean Well LED Drivers / Power Supplies - IP Rated

Specifications
Attribute Value
Input Voltage 180 → 305 V ac, 255 → 431 V dc
Output Voltage 286V
Operation Constant Current
Output Current 350mA
Maximum Output Power 100W
AC or DC Input Voltage Ac, Dc
IP Rating IP67
Configuration Encapsulated
Current Rating 600mA
Number of Outputs 1
Output 286 V dc @ 350 mA
Voltage Rating 180 → 305 V ac, 255 → 431 V dc
Primary Type AC-DC, DC-DC
Series ELG-100-C
Standards Met CB, CE:CCC, CULus Recognized, EN61347-1, EN61347-2-13, EN62384, ENEC, PFC, UL8750
3 In stock for FREE next working day delivery
Price Each
£ 27.45
(exc. VAT)
£ 32.94
(inc. VAT)
Units
Per unit
1 - 4
£27.45
5 +
£26.08
