ILH-IB01-BBEM-SC201-WIR200. ILS, 1050nm IR LED, SMD package

RS Stock No.:: 191-8854
Mfr. Part No.:: ILH-IB01-BBEM-SC201-WIR200.
Brand:: Intelligent LED Solutions

ILH-IB01-BBEM-SC201-WIR200. ILS, 1050nm IR LED, SMD package

View all IR LEDs

11 In stock - FREE next working day delivery available

Added

View Basket

Price Each

£8.26

(exc. VAT)

£9.91

(inc. VAT)

Units	Per unit
1 - 4	£8.26
5 - 9	£7.84
10 - 29	£7.31
30 +	£7.13

RS Stock No.:: 191-8854
Mfr. Part No.:: ILH-IB01-BBEM-SC201-WIR200.
Brand:: Intelligent LED Solutions

Technical Reference

Datasheet ILH-IB01-BBEM-SC201-WIR200.

Legislation and Compliance

COO (Country of Origin):: GB

Product Details

Up to 50,000 hours lifetime to 70% of original brightness
PowerStars contain 1 OSLON® Black Flat LEDs
Secondary Lens can be fitted – check options in suitable Lens and Reflector section
Suitable Heatsinks available – check options in Heatsink section
Matching Power Supply available - check options in Power Supply section
Mounting holes using M3 screws allow easy installation
Available with 200mm connecting wires
Size: (LxWxH) 20x20x2.3mm
PowerStars can be linked together to produce longer chains
Current range: 0-500mA
Applications
Infrared Spectroscopy
Medical
Wearables

Specifications

Attribute	Value
Peak Wavelength	1050nm
Radiant Flux	16mW
Mounting Type	Surface Mount
Angle of Half Intensity	120°
Number of LEDs	1
Dimensions	20 x 20 x 2.3mm
LED Material	Aluminium
Maximum Supply Voltage	3.5V

RS Stock No.:: 191-8854
Mfr. Part No.:: ILH-IB01-BBEM-SC201-WIR200.
Brand:: Intelligent LED Solutions

Datasheet ILH-IB01-BBEM-SC201-WIR200.

ILH-IB01-BBEM-SC201-WIR200. ILS, 1050nm IR LED, SMD package
