EMS, ABS Project Box, Black, 48 x 96 x 75mm

  • RS Stock No. 508-677
  • Mfr. Part No. 2704/3
  • Brand EMS
Technical Reference
Legislation and Compliance
RoHS Certificate of Compliance
COO (Country of Origin): GB
Product Details

Panel Mounted Cases

Perfect for enclosing instruments or P.C. boards that need to be panel mounted
Moulded in flame retardant ABS
Conforms with DIN43700
Moulded guides for 2 horizontally mounted PCBs (1.6mm thick)
Slots in rear for PCB edge plugs (50mm for stock no. 508-706, 65mm for stock nos. 508-677 and 508-683) and socket mounting pillars for PCB edge connectors
Front panel projection 7.5mm, 10mm; Case wall thickness 2mm

Supplied with

Grey tinted acrylic filter and natural aluminium front panel both of which can be utilised behind the clip-on bezel.

Approvals

DIN 43700

Specifications
Attribute Value
Body Material ABS
External Length 75 mm
External Width 96 mm
External Height 48 mm
External Dimensions 48 x 96 x 75mm
Colour Black
38 In stock for FREE next working day delivery
Price Each
£ 15.49
(exc. VAT)
£ 18.59
(inc. VAT)
Units
Per unit
1 - 9
£15.49
10 - 14
£14.70
15 +
£14.23
