Bourns 2011 Series 60/350V SMD Surge Arrester Gas Discharge Tube (GDT)

  • RS Stock No. 184-6120
  • Mfr. Part No. 2011-15-SMH-LF
  • Brand Bourns
Technical Reference
Legislation and Compliance
RoHS Certificate of Compliance
COO (Country of Origin): CR
Product Details

GDT Surge arrestors with Bourns patented FLAT® technology provide an innovative solution for electronic products requiring robust overvoltage protection in a compact and low profile package. The FLAT® Series is a significant leap forward in technology and is designed to meet or exceed GDT requirements as specified in ITU K.12. Bourns offers this fast acting 2-electrode Gas Discharge Tube (GDT) in an innovative flat package design. The Model 2011 Series with FLAT® Technology provides a volume and space-saving solution for high density and space-restricted PCB applications.

Bourns® FLAT® GDT technology
Improved impulse performance
Flexible mounting options
Stable breakdown throughout life
Volume- and space-saving design
Halogen free
Applications
Telecommunications
Industrial Communications
Surge Protective Devices
High density PCB assemblies

Specifications
Attribute Value
Series 2011
Suppressor Type Surge Arrester
DC Spark Over Voltage 60/350V
Impulse Spark Over Voltage 650V
Maximum Voltage Rating 150 V
Mounting Type Surface Mount
Dimensions 9.5 x 8 x 2mm
Depth 8mm
Height 2mm
Length 9.5mm
Maximum Operating Temperature +90°C
Minimum Operating Temperature -40°C
Capacitance <2.9pF
Available to back order for despatch 26/11/2020
Price Each (In a Box of 500)
£ 0.565
(exc. VAT)
£ 0.678
(inc. VAT)
Units
Per unit
Per Box*
500 - 1000
£0.565
£282.50
1500 +
£0.548
£274.00
*price indicative
