- RS Stock No.:
- 183-3183
- Mfr. Part No.:
- AMZ0050J68100000000
- Brand:
- NISSEI
220 In stock - FREE next working day delivery available
110 available from Europe for delivery within 5 working day(s).
Added
Price Each (In a Pack of 10)
£0.345
(exc. VAT)
£0.414
(inc. VAT)
| Units | Per unit | Per Pack* |
| 10 - 10 | £0.345 | £3.45 |
| 20 + | £0.313 | £3.13 |
| *price indicative | ||
- RS Stock No.:
- 183-3183
- Mfr. Part No.:
- AMZ0050J68100000000
- Brand:
- NISSEI
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- JP
Product Details
NISSEI Polyester Capacitor
The NISSEI AMZ series, 680pF is a through-hole mount polyester capacitor. It has a voltage rating of 50VDC.
Features and Benefits
• Auto insertion
• Insulation resistance is 30000mohm
• Lead pitch is 3.5mm
• Operating temperature ranges between -40°C and 85°C
• Small allowance in the lead pitch dimensions
• Small size, in H dimension that is advantageous to save space of PCB
• Tolerance is ±5%
• Insulation resistance is 30000mohm
• Lead pitch is 3.5mm
• Operating temperature ranges between -40°C and 85°C
• Small allowance in the lead pitch dimensions
• Small size, in H dimension that is advantageous to save space of PCB
• Tolerance is ±5%
Applications
• general-purpose
• Industrial
• Snubber circuits
• Industrial
• Snubber circuits
Certifications
• ANSI/ESD S20.20:2014
• BS EN 61340-5-1:2007
Specifications
Attribute | Value |
|---|---|
| Capacitance | 680pF |
| Voltage | 50V dc |
| Mounting Type | Through Hole |
| Tolerance | ±5% |
| Series | AMZ |
| Lead Pitch | 3.5mm |
| Length | 5mm |
| Depth | 2.8mm |
| Height | 7mm |
| Dimensions | 5 x 2.8 x 7mm |
| Minimum Operating Temperature | -40°C |
| Maximum Operating Temperature | +85°C |
| Dissipation Factor | 0.008% |
| Lead Diameter | 0.5mm |
