6 Way Surface Mount DIP Switch SPST

  • RS Stock No. 877-8473
  • Mfr. Part No. 90HBW06PT
  • Brand Grayhill
Technical Reference
Legislation and Compliance
RoHS Certificate of Compliance
COO (Country of Origin): CN
Product Details

Low Profile Series 90HB

Compatible with SMT assembly, including Reflow and Vapour-Phase
Top seal withstands high pressure aqueous cleaning
Maximum process temperature of 260 ºC
Polyimide film tape seal

Dual-In-Line Switches

Sub-miniature switches in a choice of configurations and actions. Note that these switches are not suitable for immersion cleaning unless stated otherwise.

Specifications
Attribute Value
Contact Configuration SPST
Contact Current Rating 3 A
Contact Material Copper Alloy
Number of Positions 6
Mounting Type Surface Mount
Actuator Type Slide
Package Style SMT
Mechanical Life 2000Operations
Maximum Operating Temperature +85°C
Minimum Operating Temperature -40°C
Operating Temperature Range -40 → +85°C
Dielectric Strength 500V
Available to back order for despatch 31/12/2020
Price Each
£ 2.00
(exc. VAT)
£ 2.40
(inc. VAT)
Units
Per unit
1 - 9
£2.00
10 - 24
£1.94
25 - 49
£1.89
50 - 99
£1.84
100 +
£1.79
