Omron 16 Way Through Hole DIP Switch, Rotary Cone Actuator
- RS Stock No.:
- 319-3773
- Mfr. Part No.:
- A6A-16C
- Brand:
- Omron
Available to back order for despatch 28/03/2025
Added
Price Each
£6.24
(exc. VAT)
£7.49
(inc. VAT)
| Units | Per unit |
| 1 + | £6.24 |
- RS Stock No.:
- 319-3773
- Mfr. Part No.:
- A6A-16C
- Brand:
- Omron
Technical Reference
Legislation and Compliance
RoHS Status: Not Applicable
Product Details
DIP Sealed Rotary Switches (IP64)
A range of PCB mount sealed rotary DIP switches. Series includes a standard type that can be operated from the top or side, spindle shaft type that can be operated while mounted on a panel, along with thumbwheel and flat options.
Fully sealed to IP64
RoHS compliant
10 or 16way switching positions
Switching capacity 1mA to 0.1A @ 5 to 28Vdc
Contact resistance 200mΩ max.
Ambient temperature -10 to +70°C
Footprint/Pin spacing: 2.54mm between pins and 5.08 between rows
Gold plated contacts
RoHS compliant
10 or 16way switching positions
Switching capacity 1mA to 0.1A @ 5 to 28Vdc
Contact resistance 200mΩ max.
Ambient temperature -10 to +70°C
Footprint/Pin spacing: 2.54mm between pins and 5.08 between rows
Gold plated contacts
PCB Mounting
Footprint/pin spacing: 2.54mm between pins and 5.08mm between rows
Specifications
Attribute | Value |
|---|---|
| Number of Positions | 16 |
| Mounting Type | Through Hole |
| Package Style | DIP |
| Actuator Type | Rotary Cone |
| Contact Current Rating | 100 mA@ 30 V dc |
| Mechanical Life | 10000Operations |
| Maximum Operating Temperature | +70°C |
| Minimum Operating Temperature | -10°C |
| Operating Temperature Range | -10 → +70°C |
| Voltage Rating | 28V dc |
| Dielectric Strength | 250V ac |
