RS PRO Grey DIN Rail Terminal Block, 10mm², Double-Level, Spring Clamp Termination
- RS Stock No.:
- 763-7527
- Brand:
- RS PRO
12750 In stock - FREE next working day delivery available
Added
Price Each (In a Pack of 10)
£2.135
(exc. VAT)
£2.562
(inc. VAT)
| Units | Per unit | Per Pack* |
| 10 - 50 | £2.135 | £21.35 |
| 60 - 110 | £2.028 | £20.28 |
| 120 + | £1.947 | £19.47 |
| *price indicative | ||
- RS Stock No.:
- 763-7527
- Brand:
- RS PRO
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- DE
Product Details
Spring Terminals
A range of spring feed through DIN Rail terminals with a proven tension spring connection system for the smallest cross sections ranging from 0.2mm² up to 16mm². This system provides safe and quick connections for solid and stranded wires, with or without wire-end ferrules. The earth terminals feature a PE foot contact that is snapped on, ensuring mechanical and electrical safety on both sides of the terminal without screws.
Specifications
Attribute | Value |
|---|---|
| Colour | Grey |
| Number of Levels | Double |
| American Wire Gauge | 16 → 6AWG |
| Series | ZRK |
| Termination Method | Spring Clamp |
| Cable CSA | 10mm² |
| Voltage Rating | 1 kV |
| Current Rating | 57A |
| Minimum Operating Temperature | -40°C |
| Maximum Operating Temperature | +120°C |
