Carlo Gavazzi SPD Switch Mode DIN Rail Power Supply, 85 → 264 V ac / 90 → 375V dc ac, dc Input, 24V dc dc
- RS Stock No.:
- 857-7384
- Mfr. Part No.:
- SPD24301
- Brand:
- Carlo Gavazzi
28 In stock - FREE next working day delivery available
1 available from Europe for delivery within 1 working day(s).
Added
Price Each
£73.46
(exc. VAT)
£88.15
(inc. VAT)
| Units | Per unit |
| 1 + | £73.46 |
- RS Stock No.:
- 857-7384
- Mfr. Part No.:
- SPD24301
- Brand:
- Carlo Gavazzi
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- TW
Product Details
Carlo Gavazzi SPD Series Switch Mode Power Supply
SPD series switch mode power supplies provide the user with an Automation-specific designed unit suitable for a comprhensive range of applications. Mounting is made very simple thanks to DIN rail mounting, coupled with a compact construction this Power Supply series can be used in space-restricted applications
Universal AC input range to cover your application
Highly efficient design
Integrated internal filter
LED indication for both DC power ON & DC low
Overload & short circuit protection
Can be mounted onto either 7.5 or 15mm DIN rail
Highly efficient design
Integrated internal filter
LED indication for both DC power ON & DC low
Overload & short circuit protection
Can be mounted onto either 7.5 or 15mm DIN rail
Switch Mode - Carlo Gavazzi
Specifications
Attribute | Value |
|---|---|
| Type | Switch Mode |
| Output Voltage | 24V dc |
| Output Current | 1.25A |
| AC or DC Input Voltage | ac, dc |
| AC or DC Output Voltage | dc |
| Input Voltage | 85 → 264 V ac / 90 → 375V dc |
| Power Rating | 30W |
| Electrical Phase | 1 |
| Number of Outputs | 1 |
| Height | 90mm |
| Width | 90mm |
| Depth | 115mm |
| Series | SPD |
| MTBF | 588000h |
| Load Regulation | ±0.5% |
| Maximum Temperature | +71°C |
| Minimum Temperature | -40°C |
| Ripple And Noise | 50mV Pk-Pk |
| Mounting Type | DIN Rail Mount |
