Glenair MWDM 37 Way Panel Mount D-sub Connector Plug
- RS Stock No.:
- 612-6316
- Mfr. Part No.:
- MWDM2L-37PS
- Brand:
- Glenair
3 In stock - FREE next working day delivery available
4 available from Europe for delivery within 1 working day(s).
Added
Price Each
£171.93
(exc. VAT)
£206.32
(inc. VAT)
| Units | Per unit |
| 1 - 24 | £171.93 |
| 25 - 74 | £154.74 |
| 75 - 199 | £140.98 |
| 200 - 399 | £128.95 |
| 400 + | £120.35 |
- RS Stock No.:
- 612-6316
- Mfr. Part No.:
- MWDM2L-37PS
- Brand:
- Glenair
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- GB
Product Details
Metal Shell Unterminated
Solder cups will accommodate 26 AWG cable and smaller
Splayed solder cup rows to aid user assembly
Splayed solder cup rows to aid user assembly
Standards
Mil-PRF-83513,
BS9523-F0002
BS9523-F0002
Micro D 0.05inch Pitch
Designed for use in electronic systems in commercial and military aerospace, military land and sea and industrial/telecommunication applications, the Micro D connector provides exceptional mechanical and electrical integrity, whilst operating in extreme vibration and environmental conditions.
High Performance, Gold Plated Twist Pin Contact System
3 Amp Contact Rating
High Density .050” Contact Pitch
RoHS Compliant
High Performance Liquid Crystal Polymer moulded connector housing with trapezoidal polarisation.
3 Amp Contact Rating
High Density .050” Contact Pitch
RoHS Compliant
High Performance Liquid Crystal Polymer moulded connector housing with trapezoidal polarisation.
Specifications
Attribute | Value |
|---|---|
| Number of Contacts | 37 |
| Gender | Male |
| Body Orientation | Straight |
| Mounting Type | Panel Mount |
| D Connector Type | Micro-D |
| Termination Method | Solder |
| Current Rating | 3A |
| Housing Material | Aluminium |
| Length | 37.72mm |
| Width | 7.82mm |
| Depth | 15.65mm |
| Series | MWDM |
| Contact Material | Beryllium Copper |
| Dimensions | 37.72 x 7.82 x 15.65mm |
| Contact Plating | Gold over Nickel |
| Minimum Operating Temperature | -55.0°C |
| Maximum Operating Temperature | +150°C |
