Amphenol ICC DDM 50 Way Right Angle Through Hole D-sub Connector Plug, 2.76mm Pitch
- RS Stock No.:
- 182-2291
- Mfr. Part No.:
- DDM50P500M
- Brand:
- Amphenol ICC
60 In stock - FREE next working day delivery available
Added
Price Each (In a Tray of 20)
£17.033
(exc. VAT)
£20.44
(inc. VAT)
| Units | Per unit | Per Tray* |
| 20 - 20 | £17.033 | £340.66 |
| 40 + | £16.59 | £331.80 |
| *price indicative | ||
- RS Stock No.:
- 182-2291
- Mfr. Part No.:
- DDM50P500M
- Brand:
- Amphenol ICC
Technical Reference
Legislation and Compliance
Non Compliant
- COO (Country of Origin):
- IN
Product Details
Suitable for high performance applications particularly in the field of Telecommunications, data transmission, automatic branch switching
Available for PCB & Cable applications
Signal - 09 to 50 position connectors, Power - wide range of layouts from 2V2 to 36W4
Use machined contacts in solder bucket, straight and right angled termination
Available for PCB & Cable applications
Signal - 09 to 50 position connectors, Power - wide range of layouts from 2V2 to 36W4
Use machined contacts in solder bucket, straight and right angled termination
High Performance D-Sub Power Board Mount Connec4tors, Input Output Connectors, machined contacts 50 Way Pin Right Angle
Specifications
Attribute | Value |
|---|---|
| Number of Contacts | 50 |
| Gender | Male |
| Body Orientation | Right Angle |
| Mounting Type | Through Hole |
| Pitch | 2.76mm |
| D-Sub Shell Size | D |
| Termination Method | Solder |
| Current Rating | 7.5A |
| Mixed Contact Layout | 50W2 |
| Housing Material | Thermoplastic |
| Voltage Rating | 300.0 V |
| Length | 66.55mm |
| Width | 11.3mm |
| Depth | 15.37mm |
| Contact Material | Brass |
| Dimensions | 66.55 x 11.3 x 15.37mm |
| Contact Plating | Gold over Nickel |
| Series | DDM |
| Maximum Operating Temperature | +125°C |
| Minimum Operating Temperature | -55.0°C |
