Norcomp 172 15 Way Through Hole D-sub Connector Plug, 2.54mm Pitch, with 4-40 Spacer/Board Lock
- RS Stock No.:
- 174-8814
- Mfr. Part No.:
- 172-E15-113R911
- Brand:
- Norcomp
78 In stock - FREE next working day delivery available
Added
Price Each
£4.96
(exc. VAT)
£5.95
(inc. VAT)
| Units | Per unit |
| 1 - 4 | £4.96 |
| 5 - 24 | £4.53 |
| 25 - 49 | £4.19 |
| 50 - 99 | £3.90 |
| 100 + | £3.66 |
- RS Stock No.:
- 174-8814
- Mfr. Part No.:
- 172-E15-113R911
- Brand:
- Norcomp
Legislation and Compliance
- COO (Country of Origin):
- TW
Product Details
Dip solder d-subs available in 5 industry sizes/positions
Standard Density (9 pin, 15 pin, 25 pin, 37 pin, 50 pin).
Nickel shells available only. Low cost economy series.
Male shells have indents to provide grounding and additional retention.
Screw machined contacts offer high reliability. Non-removable contacts.
Optional mounting hardware available
Shell: Steel, Nickel plated
Insulator: Glass-filled thermoplastic. (260°C process temp)
Machined contacts: Male pins - Brass | Female pins - Brass
Plating: Gold flash on entire contact
Standard Density (9 pin, 15 pin, 25 pin, 37 pin, 50 pin).
Nickel shells available only. Low cost economy series.
Male shells have indents to provide grounding and additional retention.
Screw machined contacts offer high reliability. Non-removable contacts.
Optional mounting hardware available
Shell: Steel, Nickel plated
Insulator: Glass-filled thermoplastic. (260°C process temp)
Machined contacts: Male pins - Brass | Female pins - Brass
Plating: Gold flash on entire contact
Specifications
Attribute | Value |
|---|---|
| Number of Contacts | 15 |
| Gender | Male |
| Body Orientation | Straight |
| Mounting Type | Through Hole |
| Pitch | 2.54mm |
| D Connector Type | Standard D-Sub |
| D-Sub Shell Size | D |
| Mounting Hardware | 4-40 Spacer/Board Lock |
| Termination Method | Solder |
| Current Rating | 5.0A |
| Housing Material | Steel |
| Voltage Rating | 500.0 V |
| Length | 39.116mm |
| Width | 12.446mm |
| Depth | 12.446mm |
| Dimensions | 39.116 x 12.446 x 12.446mm |
| Contact Plating | Gold Flash |
| Contact Material | Brass |
| Series | 172 |
| Series Number | 172 |
| Minimum Operating Temperature | -50.0°C |
| Maximum Operating Temperature | +100°C |
