ITT Cannon D*W 37 Way Cable Mount D-sub Connector Socket, 1.27mm Pitch
- RS Stock No.:
- 486-000
- Mfr. Part No.:
- 115394-1007
- Brand:
- ITT Cannon
39 In stock - FREE next working day delivery available
Added
Price Each
£3.67
(exc. VAT)
£4.40
(inc. VAT)
| Units | Per unit |
| 1 + | £3.67 |
- RS Stock No.:
- 486-000
- Mfr. Part No.:
- 115394-1007
- Brand:
- ITT Cannon
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- DE
Product Details
ITT D*W Connectors (IDC Termination)
Discrete wire termination providing reliable, rapid assembly
Tinned and dimpled shell for grounding continuity
Accepts wires from 22 to 26awg
Termination tool available separately
Tinned and dimpled shell for grounding continuity
Accepts wires from 22 to 26awg
Termination tool available separately
Standards
IDC
ITT D Type Connectors
Suitable for military, industrial or commercial applications and computer interfacing etc.
Specifications
Attribute | Value |
|---|---|
| Number of Contacts | 37 |
| Gender | Female |
| Mounting Type | Cable Mount |
| Pitch | 1.27mm |
| Termination Method | IDC |
| Current Rating | 3.0A |
| Housing Material | Steel |
| Series | D*W |
| Contact Material | Copper Alloy |
| Contact Plating | Gold |
| Minimum Operating Temperature | -55.0°C |
| Maximum Operating Temperature | +125°C |
