onsemi MC14060BDG 14-stage Surface Mount Binary Counter, 16-Pin SOIC
- RS Stock No.:
- 178-4722
- Mfr. Part No.:
- MC14060BDG
- Brand:
- onsemi
Available to back order for despatch 10/06/2024
Added
Price Each (In a Tube of 48)
£0.436
(exc. VAT)
£0.523
(inc. VAT)
| Units | Per unit | Per Tube* |
| 48 - 96 | £0.436 | £20.928 |
| 144 - 480 | £0.348 | £16.704 |
| 528 - 960 | £0.274 | £13.152 |
| 1008 - 2496 | £0.228 | £10.944 |
| 2544 + | £0.223 | £10.704 |
| *price indicative | ||
- RS Stock No.:
- 178-4722
- Mfr. Part No.:
- MC14060BDG
- Brand:
- onsemi
Technical Reference
Legislation and Compliance
Product Details
4000 Series Counters & Shift Registers, ON Semiconductor
4000 CMOS Logic Family, ON Semiconductor
CMOS Family devices
Wide operating voltage range: 3 to 18V
Wide operating voltage range: 3 to 18V
Specifications
Attribute | Value |
|---|---|
| Package Type | SOIC |
| Logic Function | Counter, Divider |
| Number of Stages | 14 |
| Logic Family | 4000 |
| Mounting Type | Surface Mount |
| Counter Type | Binary |
| Operation Mode | Up Counter |
| Number of Elements | 1 |
| Pin Count | 16 |
| Minimum Operating Supply Voltage | 3 V |
| Maximum Operating Supply Voltage | 18 V |
| Dimensions | 10 x 4 x 1.5mm |
| Direction Type | Uni-Directional |
| Triggering Type | Negative Edge |
| Minimum Operating Temperature | -55 °C |
| Maximum Operating Temperature | 125 °C |
