FTDI Chip, Bridge Evaluation Board Bridge Evaluation Board for FT60x - UMFT600A-B

  • RS Stock No. 146-8965
  • Mfr. Part No. UMFT600A-B
  • Brand FTDI Chip
Technical Reference
Legislation and Compliance
RoHS Certificate of Compliance
Product Details

The UMFT60xA and UMFT60xX range of evaluation/development modules incorporate either HSMC/FMC(LPC) connectors for interfacing FTDI’s FT600/FT601 USB 3.0 Super speed IC with external hardware. The series allows for bridging a FIFO bus to a USB3.0 host and evaluating the functionality of the FT600/FT601. As a daughter card, the UMFT60xx must work with a FIFO master board which has either a FMC or HSMC connector.

Support for USB3.0 SuperSpeed
4 IN channels and 4 OUT channels on FIFO bus connectivity
Vendor class USB device with D3xx driver support on the UMFT600x/UMFT601X for generic high speed, high volume applications such as data logging and image transfer
UVC class USB device targeted at facilitating imaging applications supported by the UMFT602x
4 IN channels and 4 out channels on FIFO bus connectivity

Specifications
Attribute Value
Kit Classification Evaluation Kit
For Use With FT60x
Kit Name Bridge Evaluation Board
4 In stock - FREE next working day delivery available
Price 1 Box of 1
£ 64.96
(exc. VAT)
£ 77.95
(inc. VAT)
Box(es)
1 - 4
£64.96
5 - 9
£52.66
10 - 24
£51.28
25 - 49
£49.96
50 +
£48.71
