Wurth Elektronik 2 x 6.8 mH 1.5 A Common Mode Choke 2 x 0.2Ω
- RS Stock No.:
- 163-7889
- Mfr. Part No.:
- 7446222007
- Brand:
- Wurth Elektronik
Available to back order for despatch when stock is available
Added
Price Each (In a Box of 91)
£3.27
(exc. VAT)
£3.92
(inc. VAT)
| Units | Per unit | Per Box* |
| 91 - 91 | £3.27 | £297.57 |
| 182 + | £2.779 | £252.889 |
| *price indicative | ||
- RS Stock No.:
- 163-7889
- Mfr. Part No.:
- 7446222007
- Brand:
- Wurth Elektronik
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- TH
Product Details
Wurth WE-LF Series Common Mode Chokes
Dual toroidal-core chokes for use in mains filter circuits
The high-quality core material allows suppression over a wide frequency range
4-pin housing
Toroidal-core chokes with segment winding
Good suppression of common-mode interference in the low- to medium- frequency range
Limited leakage field
The high-quality core material allows suppression over a wide frequency range
4-pin housing
Toroidal-core chokes with segment winding
Good suppression of common-mode interference in the low- to medium- frequency range
Limited leakage field
Applications: Mains filters, power electronics, switched-mode power supply units
Approvals
UL
Wurth Leaded Inductors (Chokes)
Specifications
Attribute | Value |
|---|---|
| Inductance | 2 x 6.8 mH |
| Series | WE-LF |
| Impedance | 200 mΩ |
| Test Frequency | 10 KHz |
| DC Resistance | 2 x 0.2Ω |
| Maximum Current | 1.5 A |
| Dimensions | 23.5 x 16 x 25.5mm |
| Operating Temperature Range | -40°C → +125°C |
| Mounting Type | Through Hole |
| Height | 25.5mm |
| Depth | 16mm |
| Minimum Operating Temperature | -40°C |
| Length | 23.5mm |
| Maximum Operating Temperature | +125°C |
