Ohmite, 25Ω 55W Wire Wound Chassis Mount Resistor F55J25R ±5%

View all Chassis Mount Resistors
Discontinued
RS Stock No.:
893-5412
Mfr. Part No.:
F55J25R
Brand:
Ohmite
Find similar products by selecting one or more attributes.
Select all

Brand

Ohmite

Resistance

25Ω

Power Rating

55W

Series

F55

Package/Case

Planar

Tolerance

±5%

Technology

Wire Wound

Minimum Operating Temperature

+25°C

Maximum Operating Temperature

+350°C

Minimum Temperature Coefficient

-260ppm/°C

Maximum Temperature Coefficient

+260ppm/°C

Dimensions

88.9 x 25.4 x 14.28mm

Overall Width

25.4mm

Overall Height

14.28mm

Overall Length

88.9mm

Non Compliant

COO (Country of Origin):
MX

250 Series Thin Stackable Resistors


Ohmite 250 series thin stackable resistors are ideal when working space is limited. These oval-shaped ceramic-core resistors feature a low profile to permit installation in spaces with height restrictions. They are also equipped with integral mounting brackets so they can be fastened to a chassis and stacked in locations with limited surface area. When properly fastened, the mounting brackets add a heat sinking benefit resulting in a smaller size per watt. The 250 series resistors are fully welded and coated with lead free vitreous enamel.

Small size-to-power ratio
Stackable
Integral mounting bracket conducts heat to mounting surface
Low profile for use in equipment where space is limited
All-welded construction
RoHS compliant
