- RS Stock No.:
- 182-3886
- Brand:
- RS PRO
- RS Stock No.:
- 182-3886
- Brand:
- RS PRO
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- TW
Product Details
RS PRO Ceramic Cartridge Fuse
The RS PRO time lag ceramic cartridge fuse has a voltage rating of 500VAC and current rating of 2A. The fuse has a size of 5x20mm and speed marking M. The body is a non-transparent ceramic tube which does not allow breaking or deformation.
Features and Benefits
Diameter of ceramic: 4.5mm ± 0.2mm
Nickel plated caps
Operating temperature ranges between -55°C and 125°C
Two nickel-plated brass end caps for good conductivity
Nickel plated caps
Operating temperature ranges between -55°C and 125°C
Two nickel-plated brass end caps for good conductivity
Applications
Telecommunication industry
Specifications
Attribute | Value |
---|---|
Current Rating | 2A |
Fuse Size | 5 x 20mm |
Fuse Speed | M |
Voltage Rating | 500V ac |
Body Material | Ceramic |
