FAG 1311-TVH Self Aligning Ball Bearing- Open Type 55mm I.D, 120mm O.D
- RS Stock No.:
- 190-8319
- Mfr. Part No.:
- 1311-TVH
- Brand:
- FAG
Available to back order for despatch when stock is available
Added
Price Each
£105.13
(exc. VAT)
£126.16
(inc. VAT)
| Units | Per unit |
| 1 - 4 | £105.13 |
| 5 - 9 | £100.93 |
| 10 - 24 | £98.83 |
| 25 + | £96.72 |
- RS Stock No.:
- 190-8319
- Mfr. Part No.:
- 1311-TVH
- Brand:
- FAG
Technical Reference
Legislation and Compliance
Product Details
If there is skewing between the outer and inner ring (for the compensation of angular misalignments)For bearing arrangements with high radial loadsFor higher speeds on account of their point contact, than barrel roller bearings with line contactWhere bearings with the above-mentioned characteristics are expected to run more quietly and at lower temperatures, even at high speeds
Specifications
Attribute | Value |
|---|---|
| Inside Diameter | 55mm |
| Outside Diameter | 120mm |
| Race Width | 29mm |
| Ball Bearing Type | Self Aligning Ball Bearing |
| Sealing Arrangement | Open Type |
| Bearing Clearance | CN |
| Material | Steel |
| Ball Material | Steel |
| Cage Material | Polyamide |
| Number of Rows | 2 |
| Static Load Rating | 17.9kN |
| Dynamic Load Rating | 52kN |
| Bore Type | Parallel |
| Bearing Series | 3 Medium |
| Race Type | Plain |
| Partial Bearing Code | 1311 |
