Nichicon 6800μF Aluminium Electrolytic Capacitor 25V dc, Radial, Through Hole - UVR1E682MHD
- RS Stock No.:
- 862-3190
- Mfr. Part No.:
- UVR1E682MHD
- Brand:
- Nichicon
This product is currently unavailable to backorder.
Unfortunately, we don’t have this product in stock and it’s not available to backorder at this time.
Added
Price Each
£1.36
(exc. VAT)
£1.63
(inc. VAT)
| Units | Per unit |
| 1 - 24 | £1.36 |
| 25 + | £1.27 |
- RS Stock No.:
- 862-3190
- Mfr. Part No.:
- UVR1E682MHD
- Brand:
- Nichicon
Technical Reference
Legislation and Compliance
Product Details
Nichicon VR Series General Purpose Electrolytic Capacitors
Nichicon VR Series Aluminium Electrolytic Capacitors are high reliability capacitors which have a rated life up to 2000 hours. The VR series capacitors offer a high temperature range, high voltage, low impedance and high ripple current.
Features & Benefits:
High reliability
High ripple current
Long life up to 2000 hours
Lead free reflow soldering
Capacitance values up to 33000 μF
High ripple current
Long life up to 2000 hours
Lead free reflow soldering
Capacitance values up to 33000 μF
Specifications
Attribute | Value |
|---|---|
| Capacitance | 6800µF |
| Voltage | 25V dc |
| Mounting Type | Radial, Through Hole |
| Technology | Aluminium Electrolytic |
| Dimensions | 18 (Dia.) x 35.5mm |
| Height | 35.5mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 18mm |
| Maximum Operating Temperature | +85°C |
| Lifetime | 2000h |
| Lead Pitch | 7.5mm |
| Tolerance | ±20% |
| Series | VR |
| Ripple Current | 2.9A |
| Leakage Current | 5100 μA |
