Nichicon 150μF Aluminium Electrolytic Capacitor 400V dc, Snap-In - LLS2G151MELA
- RS Stock No.:
- 846-7192
- Mfr. Part No.:
- LLS2G151MELA
- Brand:
- Nichicon
54 In stock - FREE next working day delivery available
14 available from Europe for delivery within 1 working day(s).
Added
Price Each (In a Pack of 2)
£3.02
(exc. VAT)
£3.62
(inc. VAT)
| Units | Per unit | Per Pack* |
| 2 - 18 | £3.02 | £6.04 |
| 20 - 48 | £2.43 | £4.86 |
| 50 - 248 | £2.19 | £4.38 |
| 250 - 498 | £1.76 | £3.52 |
| 500 + | £1.43 | £2.86 |
| *price indicative | ||
- RS Stock No.:
- 846-7192
- Mfr. Part No.:
- LLS2G151MELA
- Brand:
- Nichicon
Technical Reference
Legislation and Compliance
Product Details
Nichicon LS Series, General Purpose, Snap-In Aluminium Electrolytic Capacitors
Nichicon LS series are standard 85⁰C snap-in aluminium electrolytic capacitors. They can withstand 3000 h of rated ripple current with voltage ranging from 16 V to 450 V. These high performance and high capacitance parts are ideal for filtering and storing input current.
Specifications
Attribute | Value |
|---|---|
| Capacitance | 150µF |
| Voltage | 400V dc |
| Mounting Type | Snap-In |
| Technology | Aluminium Electrolytic |
| Dimensions | 25 (Dia.) x 30mm |
| Height | 30mm |
| Minimum Operating Temperature | -25°C |
| Diameter | 25mm |
| Maximum Operating Temperature | +85°C |
| Lifetime | 3000h |
| Lead Pitch | 10mm |
| Series | LS |
| Leakage Current | 0.73 mA |
| Tolerance | ±20% |
| Ripple Current | 1.27A |
