Nichicon 10000μF Electrolytic Capacitor 50V dc Through Hole - LGU1H103MELC

  • RS Stock No. 846-6956
  • Mfr. Part No. LGU1H103MELC
  • Brand Nichicon
Technical Reference
Legislation and Compliance
RoHS Certificate of Compliance
Product Details

Aluminium Electrolytic Capacitors GU Series 105°C

Nichicon GU Series Snap-In Aluminium Electrolytic Capacitors can withstand 3000 hours of rated ripple current application. The snap-in terminal GU Series Aluminium Electrolytic Capacitors from Nichicon offer a large capacitance range with voltages ranging from 16 to 450V. These high performance capacitors have a wide temperature range which is ideal for applications such as uninterruptible power supplies, electric pump motors, and AC servomotors.

Snap-In terminals
Endurance rating ripple current 3000 hours guaranteed
PET sleeve (non PVC)
Lead-free terminal plating

Specifications
Attribute Value
Capacitance 10000 µF
Voltage 50 V dc
Mounting Type Through Hole
Technology Electrolytic
Dimensions 35 (Dia.) x 40mm
Height 40mm
Minimum Operating Temperature -40°C
Diameter 35mm
Maximum Operating Temperature +105°C
Lead Pitch 10mm
Lifetime 3000h
Series GU
Tolerance ±20%
Leakage Current 2.12 mA
Ripple Current 4.07A
19 In stock for FREE next working day delivery
Price Each
£ 4.89
(exc. VAT)
£ 5.87
(inc. VAT)
Units
Per unit
1 - 9
£4.89
10 - 24
£4.41
25 - 99
£4.19
100 - 199
£3.33
200 +
£3.16
