RS PRO 220μF Aluminium Electrolytic Capacitor 35V dc, Radial, Through Hole
- RS Stock No.:
- 181-5450
- Brand:
- RS PRO
500 In stock - FREE next working day delivery available
Added
Price Each (In a Pack of 50)
£0.138
(exc. VAT)
£0.166
(inc. VAT)
| Units | Per unit | Per Pack* |
| 50 - 200 | £0.138 | £6.90 |
| 250 - 450 | £0.127 | £6.35 |
| 500 + | £0.115 | £5.75 |
| *price indicative | ||
- RS Stock No.:
- 181-5450
- Brand:
- RS PRO
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- TW
Product Details
RS PRO Electrolytic Capacitor
The RS PRO electrolytic capacitor has a safety vent design with through-hole mounting and features a capacitance of 220μF, at a rated voltage of 35VDC. The RS PRO capacitor has a lifetime of 1000 hours and tolerance is ±20%.
Features and Benefits
• Diameter is 10mm
• Dissipation factor is 12%
• Height is 12mm
• Lead pitch is 5mm
• Leakage current is 3μA
• Operating temperature ranging between -40°C and 105°C
• Ripple current is 660mA
• Working voltage is 35VDC
• Dissipation factor is 12%
• Height is 12mm
• Lead pitch is 5mm
• Leakage current is 3μA
• Operating temperature ranging between -40°C and 105°C
• Ripple current is 660mA
• Working voltage is 35VDC
Applications
• Computer peripheral
• Mother board
• Mother board
Certifications
• ANSI/ESD S20.20:2014
• BS EN 61340-5-1:2007
• BS EN 61340-5-1:2007
Specifications
Attribute | Value |
|---|---|
| Capacitance | 220µF |
| Voltage | 35V dc |
| Mounting Type | Radial, Through Hole |
| Technology | Aluminium Electrolytic |
| Dimensions | 10 (Dia.) x 12mm |
| Height | 12mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 10mm |
| Maximum Operating Temperature | +105°C |
| Lifetime | 1000h |
| Lead Pitch | 5mm |
| Tolerance | ±20% |
| Leakage Current | 3 μA |
| Ripple Current | 660mA |
| Dissipation Factor | 12% |
