Vishay 22μF Hybrid Capacitor 80V dc, Surface Mount - MAL218297701E3
- RS Stock No.:
- 174-0559
- Mfr. Part No.:
- MAL218297701E3
- Brand:
- Vishay
Discontinued product
- RS Stock No.:
- 174-0559
- Mfr. Part No.:
- MAL218297701E3
- Brand:
- Vishay
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- CN
Product Details
Hybrid Conductive Polymer Aluminium Capacitors SMD (Chip), Low Impedance
Long useful life: up to 10000 h at 105 °C
Very low ESR and high ripple current
High voltages up to 80 V
Automotive electronics
Industrial and professional applications
Telecommunications and IT
Very low ESR and high ripple current
High voltages up to 80 V
Automotive electronics
Industrial and professional applications
Telecommunications and IT
Specifications
Attribute | Value |
|---|---|
| Capacitance | 22µF |
| Voltage | 80V dc |
| Mounting Type | Surface Mount |
| Technology | Hybrid |
| Dimensions | 8.5 x 8.5 x 10.8mm |
| Height | 10.8mm |
| Length | 8.5mm |
| Depth | 8.5mm |
| Minimum Operating Temperature | -55°C |
| Diameter | 8mm |
| Maximum Operating Temperature | +105°C |
| Lead Pitch | 3.1mm |
| Lifetime | 160000 h @ +65 °C |
| Automotive Standard | AEC-Q200 |
| Series | 182 CPHZ |
| Leakage Current | 17.6 μA |
| Ripple Current | 1.55A |
| Polarised | Polar |
| Equivalent Series Resistance | 45mΩ |
| Tolerance | ±20% |
| Dissipation Factor | 0.08% |
