Epcos 5600μF Electrolytic Capacitor 450V dc Screw Mount - B43703A5568M000

  • RS Stock No. 171-3265
  • Mfr. Part No. B43703A5568M000
  • Brand EPCOS
Technical Reference
Legislation and Compliance
RoHS Certificate of Compliance
COO (Country of Origin): HU
Product Details

EPCOS Aluminium Electrolytic Capacitor

The EPCOS B43644 series aluminium electrolytic capacitor has 5600μF capacitance and is chassis mount. It has a diameter of 64.3mm, a height 143.2mm and a lead pitch of 28.5mm. This capacitor is ultra-compact and has an aluminium case with an insulated PETsleeve without an insulation sheet at the can bottom. It has snap-in solder pins to place on the PC board. The capacitor protects against overload by safety vent on the base. It requires a voltage of 450VDC and a ripple current of 15.8A.

Features and Benefits

• Extremely high CV product
• High reliability
• High ripple current capability
• 12000hrs lifetime
• Operating temperature ranges between -40°C and 85°C
• Tolerance is ±20%

Applications

• Frequency converters
• Medical appliances
• Professional power supplies
• Solar inverters
• Uninterruptible power supplies

Certifications

• IEC 60695-11-5

Specifications
Attribute Value
Capacitance 5600 µF
Voltage 450 V dc
Mounting Type Screw Mount
Technology Electrolytic
Dimensions 64.3 (Dia.) x 143.2mm
Height 143.2mm
Minimum Operating Temperature -40°C
Diameter 64.3mm
Maximum Operating Temperature +85°C
Lifetime 12000h
Lead Pitch 28.5mm
Series B43703
Dissipation Factor 0.2%
Tolerance ±20%
Equivalent Series Resistance 18mΩ
Polarised Polar
Ripple Current 15.8A
41 In stock for FREE next working day delivery
Price Each
£ 72.09
(exc. VAT)
£ 86.51
(inc. VAT)
Units
Per unit
1 - 2
£72.09
3 - 4
£65.25
5 - 9
£63.01
10 +
£61.35
