RS PRO, 5W Plug In Power Supply 5V dc, 1A, Level VI Efficiency, 1 Output Power Supply, Type G

Technical Reference
Legislation and Compliance
RoHS Certificate of Compliance
COO (Country of Origin): CN
Product Details

RS Pro USB A Plug-in Power Supply

RS Pro range of USB type A plug-in power supplies offer a compact robust power solution in accordance with level VI ratings. Provided in both UK & Euro plugtop options. The series comes equipped with industry standard protection such for over temperature, over current & over temperature.

The power supplies can be used in both recreational & commercial / office applications for personal electronic equipment such as charging smartphones or other devices. The series can also be used to power compact development boards such as a Raspberry Pi.


Features and Benefits

ErP Level VI.
Universal AC input.
5 W @ 1 A nominal load.
Industry standard protection within a robust enclosed power adapter.
MTBF > 50,000 hours.

Approvals

EN55022

Specifications
Attribute Value
Type Power Supply
Plug Type Type G
Output Voltage 5 V dc
Input Voltage 100 V ac, 110 V ac, 115 V ac, 120 V ac, 127 V ac, 220 V ac, 230 V ac, 240 V ac
Output Current 1A
Maximum Temperature +40°C
Output Connector USB Type A
Input Connector UK Plug
Number of Outputs 1
Power Rating 5W
Depth 27.5mm
Minimum Temperature 0°C
Load Regulation ±5%
Width 49.5mm
Energy Efficiency Level VI
Standards Met CE, EMI, EN 55022
Length 47.3mm
852 In stock for FREE next working day delivery
Price Each
£ 5.30
(exc. VAT)
£ 6.36
(inc. VAT)
Units
Per unit
1 - 4
£5.30
5 - 9
£5.04
10 - 24
£4.77
25 - 49
£4.51
50 +
£4.23
