• RS Stock No. 425-0142
      • Brand Apem
      • Mfr. Part No. SMFB16N1248
      Apem
      Solder Thumbwheel Switch Thumbwheel 1Ω
      Product Details

      Miniature front mounting

      Matt black edge switches with knobs engraved white on black.

      H 30.5mm, W 8mm, D35mm
      Contact Resistance: 100mΩ
      Mechanical Life: 106 Detent Operations
      Operating Temperature: -20 to +80°C
      Gold-plated break-before-make contacts
      Solder terminals
      Contact Rating: 200Vac/dc – 0.5A
      Cut out 31mm H : 8 x (No Switches + 1) + 0.8mm W

      Thumbwheel

      Specifications
      Not what you’re looking for? Select the attributes you require, then click the button below
      Output CodingHexadecimal
      Actuator TypeThumbwheel
      Terminal TypeSolder
      Contact Resistance
      Contact MaterialGold Plated
      Mechanical Life10^6Operations
      Number of Switch Positions16
      Minimum Operating Temperature-20°C
      Maximum Operating Temperature+80°C
      Operating Temperature Range-20 → +80°C
      Current Rating500mA
